2025 advanced technology two hoppers briquette making machine/honeycomb coal briquette machine

Product Categories

Zhengzhou Sinolion Equipment Co., Ltd

Contact Now

2025 advanced technology two hoppers briquette making machine/honeycomb coal briquette machine

Name: 2025 advanced technology two hoppers briquette making machinehoneycomb coal briquette machine
Brand: Sinolion
Price: 1000 USD

China 2025 advanced technology two hoppers briquette making machine/honeycomb coal briquette machine wholesale

Brand Name : Sinolion

Model Number : 180

Certification : CE,ISO9001,ISO9001-2008,ISO

Place of Origin : Henan Province, CHina

MOQ : 1 set

Price : USD 1000-4000 per set

Payment Terms : L/C, D/A, D/P, T/T, Western Union

Supply Ability : 20 sets per month

Delivery Time : 5-7 working days

Packaging Details : wooden case or standard container

Condition : New

Warranty : one year

Type : Briquette Machines,Custom design

Motor type : AC Motor,DC Motor,Other,Stepper Motor

After-sales service provided : Engineers available to service machinery overseas,Video technical support,Online support,Field maintenance and repair service,Field installation

Dimension(l*w*h) : Madel

Power(w) : 7.5-15KW

Raw material : Charcoal Powder,Coal.charcoal Powder,coal dust

Color : Client's Required,Blue,Customer's Request,green/blue/green,Customized

Briquette shape : Round,Cylinder-shaped

Capacity : 11-40 Pieces/minute

Application : BBQ,Fuel,Charcoal briquetting

Name : Briquette Press Machine,coal briquettes pressing ball briquetting roller press machine

Voltage : 380v,220V/380V/415V/460V,380v 50hz 3phase

Keyword : sawdust briquette machine supplier

Product name : Briquette press machine,Brequitte Making Machine

Weight : 3-25 ton per unit

Contact Now

2025 advanced technology two hoppers briquette making machine/honeycomb coal briquette machine

Brief Introduction of honeycomb briquette press machine:

It is maily used to process coal/charcoal powder into cylinder shape briquette with high density and standard looks,and marked with a number of holes inside the cylinder makes it seems like honeycomb,because it can increase the surface area of coal.make the full combustion of coal, to reduce rsource waste. Also our briquette machine now widely used to produce new-type ignited briquette.

Product Application

The honeycomb press machine is mainly used to make the coal briquettes in honeycomb shapes. It has been popularly used in China for almost 80 years. Previously raw coal been processed into the coal sphere slightly larger than ping-pong, and later the coal processed into one cylinder, and marked with a number of holes inside the cylinder makes it seems like honeycomb, because it can increase the surface area of coal, make the full combustion of coal, to reduce resource waste. Mostly it is used in coal, metallurgical powder, powder cold-pressing ball, refractory materials.

Suitable Raw Materials:
a.raw materail: any kind of coal and charcoal powder

b. raw material diameter: less than 3mm

c. raw material moisture content: 8-15%

d. add different binder according to your raw material and final briquettes requirements.(liquid and dry powder binder).


Advantages:1. high profit and low cost in raw material
 2. increase the net calorific value per unit volume after briquetting
 3. energy saving, friendly-environment, low-consumption
 4. no chemical addictives, no smell, no smoke
 5. easy to transport and store as densities product

Parameters
 	 			Model
 			Capacity
 			Motor power
 			Diameter of model
 			Pressure

 			LFM140
 			45-50 pieces/minute
 			7.5kw
 			140mm
 			20-35 tons

 			LFM160
 			45-50pieces/minute
 			7.5kw
 			160mm
 			20-35 tons

 			LFM180
 			20-26pieces/minute
 			11kw
 			180mm
 			35-45 tons

 			LFM220
 			20-26
 			pieces/minute
 			11kw for coal15kw for charcoal
 			220mm
 			30-40 tons


Our services
♥. Pre-sale service: design and manufacture machines for you as your special requirements,

 provide you with project, process design, and purchase programm.

 ♥. On-sale service: accompany with you to look around our factory, explain the manufacture

 process of our machines, and check the working performance of our machines.

 ♥. After-sale service: engineers are available to install and debugging equipments of the whole

 production line, besides, commissioning and training operators on site.






2025 advanced technology two hoppers briquette making machine/honeycomb coal briquette machine Images

Inquiry Cart 0

Send your message to this supplier


*From:	Your email address is incorrect!
*To:	Zhengzhou Sinolion Equipment Co., Ltd
*Subject:	Subject is empty!
*Message:	For the best results, we recommend including the following details: -Self introduction -Required specifications -Inquire about price/MOQ Characters Remaining: (0/3000) Please enter 20 to 3000 characters to contact this supplier!

Model	Capacity	Motor power	Diameter of model	Pressure
LFM140	45-50 pieces/minute	7.5kw	140mm	20-35 tons
LFM160	45-50 pieces/minute	7.5kw	160mm	20-35 tons
LFM180	20-26 pieces/minute	11kw	180mm	35-45 tons
LFM220	20-26 pieces/minute	11kw for coal 15kw for charcoal	220mm	30-40 tons
